PRODUCT CODE Body Length (mm) Compressed Length (mm) Extended Length (mm) Stroke Length (mm) Thread / Pitch Pressure / Force (n) Select
22-595-1000 300 340 595 255 M8 x 1.25 1000 Select
22-595-100 300 340 595 255 M8 x 1.25 100 Select
22-595-1050 300 340 595 255 M8 x 1.25 1050 Select
22-595-1100 300 340 595 255 M8 x 1.25 1100 Select
22-595-1150 300 340 595 255 M8 x 1.25 1150 Select
22-595-1200 300 340 595 255 M8 x 1.25 1200 Select
22-595-150 300 340 595 255 M8 x 1.25 150 Select
22-595-200 300 340 595 255 M8 x 1.25 200 Select
22-595-250 300 340 595 255 M8 x 1.25 250 Select
22-595-300 300 340 595 255 M8 x 1.25 300 Select
22-595-350 300 340 595 255 M8 x 1.25 350 Select
22-595-400 300 340 595 255 M8 x 1.25 400 Select
22-595-450 300 340 595 255 M8 x 1.25 450 Select
22-595-500 300 340 595 255 M8 x 1.25 500 Select
22-595-50 300 340 595 255 M8 x 1.25 50 Selected
22-595-550 300 340 595 255 M8 x 1.25 550 Select
22-595-600 300 340 595 255 M8 x 1.25 600 Select
22-595-650 300 340 595 255 M8 x 1.25 650 Select
22-595-700 300 340 595 255 M8 x 1.25 700 Select
22-595-750 300 340 595 255 M8 x 1.25 750 Select
22-595-800 300 340 595 255 M8 x 1.25 800 Select
22-595-850 300 340 595 255 M8 x 1.25 850 Select
22-595-900 300 340 595 255 M8 x 1.25 900 Select
22-595-950 300 340 595 255 M8 x 1.25 950 Select
